PIR Insulation Board 120mm: Flat Roofs, Upgraded Floors, and the Joist Depth Problem

The UK guide to 120mm PIR insulation: where it's specified, how far it gets towards Part L 2021 for flat roofs and floors, the joist depth trap, and how to buy Celotex XR4120 at the right price.

By Ian

Project managed a £182k Oxfordshire kitchen extension

Order too thin a PIR board for a warm deck flat roof and you can end up paying twice when building control rejects the U-value. The shortfall looks small on paper but it becomes a full strip-back once the membrane is on. 120mm PIR shows up often in flat roofs and upgraded floors, but on a new flat roof in England it no longer gets there on its own: the Part L 2021 roof limit needs about 140mm in a typical warm deck. The extra depth solves compliance, but it also brings handling and detailing issues thinner boards do not.

What it is and what it's for

PIR (polyisocyanurate) insulation at 120mm is the same rigid foam board as the thinner variants, just thicker and heavier. Same foil-faced sandwich, same closed-cell foam core, same lambda value of 0.022 W/mK. At 120mm, a single board delivers an R-value (thermal resistance, the measure of how well the board resists heat flow) of 5.45 m²K/W.

That R-value is what makes 120mm a common thickness for two specific applications where thinner boards fall short:

Flat roofs (warm deck construction). Part L 2021 sets the maximum U-value for a new flat roof, including one on an extension, at 0.15 W/m²K (0.16 W/m²K when an existing roof is renovated). In a warm deck build-up (where insulation sits above the structural deck), the Insulation Manufacturers Association's flat roof guide gives 140mm of PIR on an 18mm plywood or OSB deck for 0.15 W/m²K, and 120mm only for 0.18 W/m²K, the old pre-2022 limit. So 120mm on its own falls short on a new extension roof; take the thickness from your U-value calculation.

Floors where the building control officer upgrades the spec. The Part L extension floor U-value limit is 0.18 W/m²K in England. 100mm PIR achieves roughly 0.17 W/m²K on a solid concrete floor, which passes. But BCOs regularly ask for 120mm as a comfort margin, particularly if other elements of your thermal envelope are marginal. In Scotland, where the floor limit for extensions is a tighter 0.15 W/m²K, 120mm PIR (achieving about 0.15 W/m²K) is the usual specification.

120mm PIR brings a solid floor to about 0.15 W/m²K, the Scottish extension floor limit and a comfortable margin under England's 0.18. On a new warm deck flat roof in England it is not enough on its own: 0.15 W/m²K typically needs about 140mm.

The standard board is 2400 x 1200 mm, covering 2.88 m². Each board weighs approximately 11.3 kg. That's noticeably heavier than a 50mm board (about 4.5 kg) and worth noting if you're carrying them up a ladder to a flat roof. Two people make the job safer and faster, especially in wind.

Types, sizes, and specifications

Every major PIR brand manufactures a board in this thickness to BS EN 13165 (the European product standard for rigid PIR insulation), and the thermal performance is identical across all of them. Lambda and R-value are shared by every certified product. The differences that matter are compressive strength, price, and availability.

BrandProductLambdaCompressive strengthPrice (online specialist)Notes
CelotexXR41200.022 W/mK≥140 kPaObtain current delivered quoteWidest distribution. Stocked at Travis Perkins. The default 120mm board.
RecticelEurothane GP 120mm0.022 W/mK≥120 kPaObtain current delivered quoteIdentical thermal performance. Check local availability and the current delivered quote.
KingspanThermaroof TR26 120mm0.022 W/mK≥120 kPaObtain current delivered quoteFlat-roof board: confirm compatibility with the waterproofing system.
KingspanKooltherm K107 120mm0.019 W/mKCheck current declarationObtain current delivered quotePhenolic pitched-roof board, not a like-for-like warm flat-roof replacement.

Matching thermal conductivity does not make roof boards interchangeable. Facing, fixing method and waterproofing compatibility matter. Kooltherm K107 has a declared lambda of 0.019 W/mK but is a pitched-roof board; do not substitute it into a warm flat roof merely to save depth.

For floor upgrades, buy Celotex XR4120 or Recticel GP 120mm: they perform identically, so get whichever is cheapest and in stock. For a new flat roof in England, order the thickness your U-value calculation gives (often 140-150mm) rather than 120mm on its own.

Tip

The Celotex product code for 120mm is XR4120, from the XR4000 range. The GA4000 range (GA4050, GA4100) only goes up to 100mm. Check the current product range and exact code on your order rather than relying on a merchant shorthand.

Compressive strength: the specification that matters for floors

This is the single most consequential technical detail most homeowner guides ignore.

PIR boards come in different compressive strength grades. Compressive strength measures how much weight the board can support without deforming, stated in kilopascals (kPa). Some wall-grade boards are rated as low as 100 kPa (the IMA gives at least 120 kPa as typical for PIR roof boards). Floor-grade boards need a minimum of 120 kPa, and products like the Celotex XR4120 exceed this at 140 kPa or above.

Why it matters: under a floor, the insulation carries the weight of the screed, the floor finish, the furniture, and everyone walking on it. A 100 kPa board used under a 65mm sand-and-cement screed will gradually compress over time, creating dips and unevenness in your finished floor. The screed cracks. The tiles crack. The repair bill runs into thousands.

Warning

If you're installing 120mm PIR under a floor screed, verify the board's compressive strength is at least 120 kPa. Wall-grade boards (100 kPa) will compress under floor loads, causing screed cracking and uneven floors. Check the datasheet, not just the thickness.

The XR4000 range, now marketed as Sopratherm (previously Celotex), has declared compressive strength of 140 kPa. Suitability still depends on its certified application and the full design. Recticel GP boards are rated at 120 kPa minimum. Both are fine for domestic floors. But if you're ordering from a less common brand or picking up seconds, check the spec sheet. Not all 120mm boards are floor-grade.

How to work with it

Handling and storage

At full-board weight, 120mm PIR is manageable for one person on the ground. Getting boards onto a flat roof is a different story. A full sheet caught by a gust of wind acts like a sail. Work in pairs when lifting to height. Stack boards flat on a clean, level surface. Don't lean them against walls at an angle, as they'll bow over days.

Store boards dry, flat, off the ground and protected from weather as the manufacturer directs. Install only as much roof insulation as can be protected by the waterproofing system, and protect exposed work if installation stops.

Cutting

At 120mm thick, score-and-snap still works but takes more effort than with thinner boards. Score the foil on one side deeply with a sharp utility knife (don't try to cut all the way through), then snap over a straight edge. The break won't be as clean as with 50mm boards. A better approach at this thickness is a fine-toothed handsaw or panel saw. Mark your cut line on the foil with a pencil, then saw through. The foam cuts easily, but keep the saw straight to avoid a wavy edge.

Correct technique for cutting 120mm PIR board: use a fine-toothed handsaw with a straight edge guide and support on both sides of the cut.

Cut 5mm oversize and trim to fit. A friction fit between joists or against a deck edge is better than a gap. Gaps get filled with expanding foam, which has inferior thermal performance to PIR and is a bodge that building control will question.

Warning

Cutting 120mm PIR produces a lot of fine dust, more than thinner boards because there's simply more material. Wear a P2 dust mask and safety glasses. If using a power tool (circular saw or reciprocating saw), expect a cloud of pink/yellow dust. Cut outdoors or with extraction.

Flat roof installation (warm deck)

The warm deck method is the standard approach for flat roof insulation in UK new builds and extensions. The PIR sits above the structural deck, with waterproofing on top of the insulation. This keeps the deck warm and eliminates condensation risk within the roof structure.

The build-up from bottom to top:

  1. Plasterboard ceiling finish
  2. Structural deck (typically 18mm OSB or plywood on timber joists)
  3. Vapour control layer (VCL), overlaps taped and sealed, minimum 100mm overlap
  4. 120mm PIR boards, staggered joints, all joints sealed with aluminium foil tape
  5. Waterproofing membrane (EPDM rubber, GRP fibreglass, or torch-on felt)

Before laying the VCL, check that the deck's moisture content is below 20% using a pin-type moisture meter. Wet timber under a VCL will rot, and you won't see it until the ceiling stains.

Seal board joints as the specified insulation system requires. Where the foil-faced layer is designed to provide air and vapour control, its joints, edges and penetrations must form a continuous seal with compatible tape. Gaps can allow heat and moisture bypass, but no universal percentage loss applies. A separate AVCL may still be required by the construction design.

Tip

The IMA (Insulation Manufacturers Association) thickness table is a typical figure, not a calculation for your roof. Thermal bridging through mechanical fixings adds a correction to the U-value, which can push the thickness up again, so ask for the U-value calculation for your actual build-up before ordering.

Floor installation

For solid concrete ground floors (the most common in extensions), the build-up is: oversite concrete or slab, DPM (damp-proof membrane), 120mm PIR, polythene separating layer, then screed.

That polythene layer between the PIR and the screed is critical. Wet cement screed is alkaline and attacks the aluminium foil facing, causing it to delaminate over time. The polythene prevents this chemical reaction and acts as a slip layer during screed curing.

Stagger board joints. Fit the specified perimeter insulation and compressible screed edge strip; do not leave an uninsulated perimeter gap. The boards carry the full weight of the screed and everything above it, which is why compressive strength grade matters.

The joist depth trap

This is the most common practical problem with 120mm PIR, and it catches people on every forum thread about this product.

If you're fitting PIR between floor joists in a suspended timber floor, the boards sit on battens or clips fixed to the joist sides, so the joists must be at least as deep as the board. A 120mm board fits between standard 150mm (6 inch) joists, but older houses can have much shallower joists. The joists also bridge the insulation, so a suspended floor needs more PIR than a solid one: one building control quick guide gives 140mm of PIR between joists to reach 0.18 W/m²K.

If the joists are shallower than the thickness your U-value calculation needs, the boards physically don't fit. The solutions are all compromises:

  • Use thinner PIR between the joists and add a layer above or below. 100mm PIR achieves about 0.17 W/m²K on a solid concrete floor, but between joists on its own it falls well short of 0.18 W/m²K.
  • Install above the joists instead of between them. This raises the floor level by 120mm plus the thickness of the new deck, which causes problems at door thresholds, stair landings, and where the extension meets the existing house.
  • Install below the joists in the void beneath. Possible in some constructions but creates vapour management problems and makes the boards harder to support long-term.

Warning

Before ordering PIR for a suspended timber floor, measure your joist depth. In older houses joists can be as shallow as 100mm, and 120mm boards won't fit between them. Check first, order second.

For new-build extensions where you're specifying the joists from scratch, specify joists at least as deep as the insulation the U-value calculation needs. The cost difference for deeper joists is minimal compared to the insulation headache of trying to work around shallow ones.

How much do you need

Each board covers 2.88 m². The calculation:

  1. Measure the total area in square metres (roof area or floor area)
  2. Divide by 2.88
  3. Add 10% for cuts and waste
  4. Round up to whole boards

Worked example: board count for a 4m x 6m flat roof (the count is the same at 140mm or 150mm)

Roof area: 24 m². Divide by 2.88 = 8.3 boards. Add 10% waste = 9.2 boards. Order 10 boards.

Multiply the board count by a current delivered quote for the specified thickness. Include VAT, minimum order and delivery charges.

Worked example: solid ground floor for the same extension

Floor area: 24 m². Same calculation: 10 boards. Same cost range. For an extension with both a flat roof and a concrete floor insulated at 120mm, you'd need approximately 20 boards.

Tip

Rounding up after the 10% waste allowance already leaves a spare board or so (10 boards for 8.3 boards of area), so there is no need to add more on top. Keep the spares on site until the waterproofing is finished: on flat roof jobs, boards sometimes get damaged during waterproofing installation, and a trip to the supplier mid-job is expensive in lost time.

Cost and where to buy

The online specialist market for PIR insulation is well-established and consistently cheaper than traditional builders' merchants.

SourceCelotex XR4120 price per boardNotes
Online Insulation SalesObtain current delivered quoteCheapest found. Free delivery over threshold.
Trade InsulationsObtain current delivered quoteAlso stocks Recticel GP at same price.
Insulation SuperstoreObtain current delivered quoteWide range. Also sells Kingspan TR26.
Insulation PointObtain current delivered quoteMid-range pricing.
Travis PerkinsTrade account onlyConfirm the current product code, board dimensions and delivered price.
JewsonAsk for quoteCan be competitive when quoted properly against online prices.

120mm PIR board (Celotex XR4120, online specialist)

£39.60 – £50.40

Roof insulation project (single-storey extension, supply and fit)

£1,000 – £2,000

PIR prices have risen in recent years and continue to fluctuate. The raw material base is oil-derived, so PIR tracks petrochemical markets. Prices can move meaningfully between when you get quotes and when you place an order, particularly in periods of broader construction cost inflation. Get quotes close to your order date rather than planning your budget on prices from several months earlier.

Compare your builder's delivered quote with an insulation specialist for the identical product, thickness and quantity. Account discounts and delivery charges can change which offer is cheaper.

Don't forget the aluminium foil tape. Budget £7 – £12 per roll. A 24 m² roof has about 30m of board joints, so one 45m roll covers it with the usual 20% allowance; buy a second if you also tape the perimeter. Also budget for the VCL membrane (around 30-50 for a roll covering 50 m²) and mechanical fixings if required by the waterproofing manufacturer's specification.

Where to buy PIR Insulation Board 120mm

Check current prices from UK suppliers.

These are affiliate links: if you buy through them we may earn a small commission, at no extra cost to you. Learn more.

Alternatives

PIR 100mm is the more common thickness. It handles walls, most floor applications in England (0.17 W/m²K against the 0.18 limit), and pitched roofs as part of a layered system. If you don't have a flat roof and your BCO hasn't asked for an upgrade, 100mm is probably what you need. It's lighter (10-12 kg per board), cheaper (£32.40 – £40.80 per board), and fits between standard 150mm joists.

PIR 150mm is the thickness many warm deck flat roofs in England need to reach the 0.15 W/m²K Part L target (the IMA table gives 140mm; one building control quick guide gives 150mm). Scotland's extension roof limit is tighter again, 0.12 W/m²K. The price premium over 120mm is moderate, but availability at specialist retailers can be inconsistent. Check stock before specifying.

Mineral wool (100-150mm) is much cheaper and non-combustible, but you need nearly double the thickness for equivalent thermal performance (mineral wool's lambda is typically 0.032-0.044 W/mK vs PIR's 0.022). For flat roofs, mineral wool isn't practical because it absorbs water and compresses under load. For suspended floors between joists, mineral wool with a breathable membrane is a valid alternative, particularly in older buildings where PIR's low vapour permeability can trap moisture.

EPS (expanded polystyrene) is budget insulation at roughly 60% of PIR's cost, but with a lambda of 0.032-0.038 W/mK, you'd need approximately 180-200mm of EPS to match what 120mm PIR achieves. Where physical depth is available (ground floors with deep voids), EPS works fine. Where depth is constrained (flat roofs, between joists), PIR is the practical choice.

Where you'll need this

  • Insulation - flat roof and floor insulation where Part L 2021 demands more than 100mm

These tasks appear across all stages of any extension or renovation project involving flat roofs or upgraded floor specifications. 120mm PIR is not specific to any one project type.

Common mistakes

Using wall-grade boards under a floor screed. This is the one that costs real money. Wall-grade PIR has a compressive strength of 100 kPa. Floor-grade needs 120 kPa minimum. A wall-grade board under a 65mm screed will slowly compress. The screed cracks. The tiles lift. The fix involves stripping the entire floor back to the insulation layer. Always check the datasheet for compressive strength before using any PIR board in a floor application.

Ordering 120mm for between-joist installation without measuring the joists. A board deeper than the joists won't fit between them, and shallow joists in older houses limit how much insulation you can get in. Measure the joist depth first, and remember the joists bridge the insulation, so a suspended timber floor needs more PIR than a solid floor for the same U-value.

Skipping the polythene layer between PIR and wet screed. As covered in the floor installation section, alkaline cement chemically attacks the foil facing. A simple polythene sheet over the PIR before screeding prevents this. Costs almost nothing. Saves the integrity of your vapour control layer.

Leaving boards exposed on a flat roof overnight without protection. Rain soaks into cut edges and untaped joints, and prolonged exposure damages the foil facing (see handling notes above). Waterproof on the same day you install the PIR. If weather forces a delay, cover the boards with weighted tarpaulin.

Not taping the joints. Same issue as thinner PIR boards, but arguably more critical at 120mm because these boards are used in flat roofs and floors where moisture management is everything. Every joint needs aluminium foil tape. Every board-to-board junction, every perimeter. In a warm deck the separate VCL under the boards does the vapour control, and taped foil joints stop warm air bypassing the insulation. Gaps mean condensation, and condensation in a flat roof means timber rot that you won't discover until the ceiling stains.

The four most costly 120mm PIR installation mistakes, and what goes wrong when you make them.

Choosing solely by lambda or price. Confirm the board is approved for the floor or roof build-up, including its facing, compressive performance, fixing and membrane compatibility. Similar thermal figures do not establish equivalent application suitability.
